Safety measures

It is the user's responsibility to apply preventive and protective measures, in
accordance with the legislation of the country of installation and use of the device.
To avoid any risk of electrical shock only the type of AC/DC power adaptor
indicated in this manual must be used.
Do not connect the units to the power supply until the end of the complete
installation and the mutual connection of the units is done.
Only connect certified peripherals/devices to the device.
Operations on the device must be carried out by specialized and authorized
personnel only.
Always disconnect the electrical power supply before carrying out any work on the
device.
Check that the electrical voltage meets the values indicated in this manual before
connecting the device. Only the connections indicated in this manual to expected
equipments are allowed.
Disconnect the device from any power source before cleaning.
The enclosure of the device must be cleaned only with a dry cloth.
Do not install this apparatus near water (e.g. near washbasins, sinks, showers,
bathtubs, swimming pool, wet floors or anything in the presence of water and
liquids in general).
Keep the device away from exposure to moisture values outside the admissible
range indicated in this manual.
The device must always be fixed to a machine before proceeding with any type of
operation and/or use.
It is strictly forbidden to modify the appliance in order not to compromise the
characteristics relating to the declared requirements.
Make sure that any part of the device cannot come in contact with an unconscious,
anaesthetized or incapacitated patient.
It is strictly forbidden to cover the device during operation.
Personnel training is a responsibility of the manufacturer of the device to which
the ComfoConnect PRO will be connected.
EN
1

Technical specifications

Product Data
Name
Number
Electrical
Nominal input voltage
Nominal input current
Nominal power consumption
Environmental
Operating temperature
Storage temperature
Humidity
Flammability rating of connectors
Flammability rating of housing
Flammability rating of PCB
Housing material
Standards
Directives and Certification
requirements
Electrical connection
ComfoConnect Pro connection
CAN_L
CAN_H
GROUND
12V
Network connection
Wi-Fi
Ethernet
Connectors
ComfoConnect PRO
30006323
+12VDC
max 2Amp
1,7 W / Max 6 W (Only if USB port in use)
-5 °C to +35 °C
-5 °C to +35 °C
< 95% (non-condensing)
UL 94 V-0
UL 94 V-0
UL 94 V-0
Plastic
RED 2014/53/EU
EN 62368-1 :2020 +A11: 2020
EN IEC 62311 :2020
ETSI EN 301 489-1 V.2.2.3
ETSI EN 301 489-17 V.3.2.4
ETSI EN 300 328 v.2.2.2
RoHS
Colors Codes (cable and connection)
WHITE
YELLOW
BLACK
RED
2,4GHz / 5GHz
10/100 Mbit
RS 232 / RS485
