TTC40F
IN20118 REV. B, 2025-10-24
Caution! Read and understand the instruction before us-
ing the product.
Caution! Ensure that the installation complies with local
safety regulations.
Warning! Before installation or maintenance, the power
supply must first be disconnected in order to prevent po-
tentially lethal electric shocks! Installation or maintenance
of this unit should only be carried out by qualified person-
nel. The manufacturer is not responsible for any eventual
damage or injury caused by inadequate skills during in-
stallation, or through removal of or deactivation of any
safety devices.
Function
Triac controller for proportional control of electric heating
TTC40F is a proportional, 3-phase electric heating controller with
automatic voltage adjustment. The controller operates through stepless,
time-proportional control, where the relationship between the on-time
and off-time is based on the current heat demand.
The controller is primarily intended for use together with Regin's NTC
series of sensors for either supply temperature control or room
temperature control. During room temperature control, the supply air
temperature can be provided with a minimum or maximum limitation.
TTC40F can control both symmetrical Y-connected 3-phase heaters and
symmetrical or asymmetrical Delta-connected heaters.
The controller is only intended for control of electric heating. The
control principle makes it unsuitable for control of motors or lighting.
TTC40F is intended for DIN-rail mounting.
Technical Data
Supply voltage 3-phase, 210...255 / 380...415 V AC 3-phase, 50...60 Hz
with automatic voltage adaptation.
Max. current: 40 A/phase.
Max. load 5300 W/phase at 230 V line voltage (40 A)
9200 W/phase at 400 V line voltage (40 A)
Min. load 530 W/phase at 230 V line voltage (4 A)
920 W/phase at 400 V line voltage (4 A)
Protection class IP20
Ambient 0...40°C, non-condensing
temperature
Installation
– Mount TTC40F on a DIN-rail in a cabinet or other casing.
– Mount the controller vertically with the text right side up.
Note! At full power, TTC40F will emit approx. 70 W of ex-
cess heat which must be properly dissipated!
Wiring
– Connect the supply voltage to the terminals L1in, L2in and L3in.
1 2 3 4 5 6 7 8 9
L1 L2 L3 L3 L2 L1 1 1 3
Figure 1 Wiring of supply voltage and load
Note! The controller must be grounded and the supply
voltage must be interlocked via a high temperature limit
switch!
TTC40F
Load
– Use terminals L1out, L2out and L3out.
– Resistive 3-phase heater without neutral connection.
Main sensor and external setpoint (figures 2-6)
– Use terminals 1 and 4 (polarity insensitive). Low voltage.
Note! Terminals 2 and 3 are internally connected and are
used to simplify wiring when using an external setpoint
potentiometer. Switch 1 is used to select internal or exter-
nal setpoint.
TG-R5xx
1 2 3 4
TG-R6xx
1
2
Figure 2 Wiring of room temperature sensor TG-R5xx or TG-R6xx when
using internal setpoint
1 2 3 4
TG-R4xx
1
3
Figure 3 Wiring of TG-R430 sensor as external sensor and setpoint
adjustment for room control
1 2 3 4 TG-K3xx
TG-G1xx
Figure 4 Wiring of floor or duct sensor when using internal setpoint
TG-K3xx 1 2 3 4
TG-R4xx
TG-G1xx
2
3
Figure 5 Wiring of an external, separate sensor and TG-R4xx as a
setpoint device only
1 (9)
