EN
FEATURES
Adjustable
thermostat
OPERATION INSTRUCTION
1. Before inserting the plug into an electrical outlet, make sure that the electrical supply
in your area matches that on the rating label on the unit.
2. Carefully remove the heater from the plastic bag and the carton.
3. Place the heater on a firm level surface.
4. Set the adjustable thermostat switch to "-".plug the cord set into a 220-240V~ 50-
60Hz,AC source.
5. This appliance is equipped with a 4-position Heating power switch
SYMBOL
6. Set the rotary switch to maximum for fast warm up of a room. Once the room is
comfortable, select a lower setting to reduce electrical consumption and to prevent the
room from becoming too warm. Adjust the thermostat to maximum and select the
desired power setting. Once the room is comfortable, rotate the thermostat
counterclockwise, until the heater shuts off. The thermostat will now maintain the
temperature by cycling the heater on or off. During particularly cold weather, the low
power setting may be insufficient to satisfy the thermostat. Select a higher setting for
these periods. Before switching off and better work for 5-10 second in cool condition.
FUNCTION
OFF
BLOW COOLING AIR
HALF HEAT OUTPUT
FULL HEAT OUTPUT
OSCILLATION
3
Switch
