- setthe charging current ( MIN,MED,MAX)usingthethree-way switchon thefront panel(forthe models
whichhavethis),depending o nthecharging current r equired;
- for battery c hargers w ithadjustable charging c urrent, thedirections g iven bythemanufacturer
shouldbefollowed. C harging normally takesabout10 hourswitha currentot 1/10(O,I) of thecapacity in Ah
of the battery.
E.g.: 40 Ah battery recommended charging current=40/10 = 4A for a minimum of 10 hours:
- afterconnecting thewiresto thebattery,supplythe batterycharger w ith avoltagewhichis equalto thevol-
tagestated on the dataplate:
- once charging i sfinished, turnthebattery charger o ffbymeans o f themain switch(ifany)or byremoving
theplug fromthepower s upply, disconnect the+and- clamps f romtheterminals a ndclose thebattery with
the caps provided;
CAUTION ! if thebattery i s leftconnected tothebattery charger for many hoursafter c harging h asfinished,
thebattery c ouldbedamaged since thecurrent n ever s witches o ffandthiscouldcause excessive heating o f
the platesandthe liquidcontained in the batterymaystartto "boil". If this phenomenon alsooccursduring
charging, thecharging c urrent s hould bedecreased (formodels w hichhave a regulator) or charging s hould
be interrupted in ordertoavoiddamaging thebattery.
TYPES OF BATTERIES
Model: lead battery No. of elemens:3; 6
MAINTENANCE
Replacement Offuses:(for themodelswhichareequipped withfuse)
01 - disconnect thepower supplycableof the battery charger ( remove theplugfrom thepower supply
socket);
02 - unscrewthe fasteningscrewsandopenthe batterycharger,CAUTION! neveruse the batterycharger
while it is open.
03- remove t heprotective c over otthefuseandreplace t hefusewithatuseof thesame value (The correct
valueof thefuseisstatedon thedataplateandnearthefuseitself);
04 - close the batterychargerand tighten the fastening screws;
Replacement ofpowersupplycable(for themodelswherethereplacement canbedonewithoutaspecial t ool)
01 - disconnectthe power supplycableof the batterycharger(removethe plug from the power supply
socket);
02 - unscrewthe fastening screwsandopenthe batterycharger.CAUTION! neveruse the batterycharger
while it is open.
03 - withdraw the connectors of the power supply cable;
04 - replace the powersupplycable, m akingsurethatit is placed as before;
05 - closethebatterycharger a ndtightenthefastening screws.
TROUBLE-SHOOTING
BATTERY CHARGERNOT CHARGING:
- checkthatthe negative (-) andpositive(+) clamps areconnected t o thecorrectterminals on thebattery;
if thereis morethanonebatteryin series, c heckthe connection between thebatteries(negative terminalof
onebattery to thepositive terminalofthe other).
Check thisagainst t hevariousconnection diagrams:
- checkthat the power supply cableis connected;
- checkthat thethermalprotection hasnot beenactivated (for modelswith resetof the external p rotection),
bymeans of a button,waitabouta minuteandpressthebuttonon thefront panel o f thebattery charger.
WARNING
Theattempt t o charge damaged b atteries o r thecontinuous shortcircuitbetween t hepliersfor longer t han
necessary, may irreparably damage the thermal protection inside the battery charger.
8
ofthebattery
RatedAh capacity:see data
plate on batterycharger
GENERAL OPERATION INSTRUCTIONS FORBATTERY CHARGER/STARTER
The starting ofavehicle u sing astarter i srequired w hen thebattery d oes nothave enough p ower t omake thestarting m otor
turn.
Proceed tofast c harge forminimum 1 0minutes with acurrent adequate
BOOSTER and attempt toBOOST START (donotinsist l onger than thetimeshown o nthetechnical data table),
IMPORTANT: when theengine i srunning, SWITCH O FF theCharger IMMEDIATELY.
anyof thevehicles' electronic devices.
After s everal attempts atstarting. theinternal protection thermostat oftheappliance may intervene,
resets after 10-15 minutes,
OPERATION INSTRUCTIONS FORPORTABLE STARTER
Therange ofbattery-Chargers/starters contains two versions.
The first v ersion operates with only 12output volts and isfitted with acharger-starter
suitable f orthereading o f thecharging c urrent (firstpartofthegraduated scale) andthestarting current (final p art o tthe
scale).
The second v ersion o perates with12/24 output v olts andinaddition t othebattery i ndicator and thecharger-starter
also hastwosockets m arked w ith12Vand24V (which canbeused separatery
Ifthe appliance istobeused a sabattery charger, connect theblack c lamp t othe- terminal and the red Clamp to+terminal
ofthebattery. Then connect thepower supply cable toa mains s ocket withsufficient power a ndturntheswitch tothemost
suitable p osition f orbattery r echarging, following t heinstructions given forordinary b attery c hargers.
If theappliance istobeused asastarter f ollow thegeneral operation instructions asabove.
OPERATION INSTRUCTIONS FORSTARTER ONWHEELS
Turnthefunctionswitch(Stow-fast charge-starter) to therequired position.
For t hemodels equipped with timer, fast c harge o perations are only possible itthetimer h as been s etwith aspecific char-
ging time.Once t histimehaselapsed, theappliance willautomatically
Whenthe switch is in STARTER position, thetimer Will not operate.
Formodels with remote control,whichcanbe usedfor starting, e nergyis delivered to thebatteryby pressing theremote,
controlbutton,whenthefunctionswitchis in "Remote Control" position.
ATTENTION
Inside t heplastic b attery charger there is afuse protection against short c ircuit (contact between positive p liers (+)and
negative pliers (-) ).
If the unitdoesn'twork,DETACH T HE PLUGOFTHEPOWER S UPPLY CABLE F ROM THE WALLOUTLET, openthe battery
charger andcontrol theinside fuseisin order. I f fuseiswrong, r eplace it withoneofthesame value.
9
tothebattery onuse. Immediately set t heswitch t o
Failure t odoso cause d amage to
which automatically
switch a nd abattery indicator which i s
switch, it
depending onthevoltage o fthebattery).
switch off.
