Aerial:Goodreception isonlypossible w itha goodaerial.Position t heaerialasfaraspossible from
theignitionassembly. T heaerialearthingbar or strapmustcontact c leanmetal. Protect thiscontact
againstcorrosion with siliconegreaseor anotherrustpreventer.
Adaptor c ables: S pecific a daptor c ables ( which simplify c onnection oftheset) a reavailable f ormany
cars. Refer t othetableat theendof thisbooklet. C ontact y ourdealerfor furtherinformation.
1 POWER SUPPLY
Voltage and polarity: Thesetmust b econnected t o a 12V carbattery withnegative terminal
to earth (carchassis).
• Use thesame earthing p oint f ortheradioandallother a udio equipment (tominimize i nterference).
Note: Permanent 12Vsupply must b econnected to ensure t hatCD*changer functions correctly.
A
WARNING:
car battery terminal until the set has been mounted and connected.
PREPARING CONNECTOR
Recommended power supply connections
BROWN lead[A8]: Connect to an earthing pointon thecarbody.
REDlead[A7]: Connect to a switched 12 V supply.
YELLOW/REDlead[Ad]: Connect to a permanent 12 V supply.
The 'ON/OFF LOGIC feature inthissetfunctions onlyif the permanent2Vsupply a ndswitch
12Vsupply a reconnected asbelow. C onsult yourcarservice m anual orcheck w ithyourdealer
to confirm this. See illustration for correct connection.
BROWN lead[A8]: Connect to an earthing pointon thecarbody.
REDlead[A7]: Connect to a permanent 12 V supply.
YELLOW/REDlead[Ad]: Connect to a switched 12 V supply.
See'INITIALISATION', o ption 'LOCI' to activatethis feature.
OPTIONAL CONNECTIONS
Electronic/motor aerial: Connect thesupply foran electronic a erialor thecontrol l eadfortherelayof an
automaticmotoraerial to pin [A5]. Usethesmallcontactsupplied
Do notusethisconnection point for directsupplyof theaerial motor!
Pilotlight:Whenthecarheadlamps a reswitched on,theon/offcontrol O Fthe r adioisilluminated (even when
theradioisswitched o ff).Connect pin[A61 tothedashboard illumination w iringOF yourcar. Usetb small
contact s upplied.
Telephon e mute:Ifyourcartelephone provides a mute signal, i tcanbeused toautomatically interrJpt the
set's audio output.Connect thetelephone mute wireto connector [A1]. Use thesmall c ontact supplied
Choose requiredsettings fromINITIALISATION mode.
PREPARING CONNECTORB (FORLOUDSPEAKERS)
Only useloudspeakers w hich havean impedance of 4 ohms.
Ensur e thattheloudspeakers areconnected in phase byusing marked speaker terminals f or thephase
(+) connections.
Do notconnectany of the loudspeakerleadsto earth!
Do notconnect a booster/amplifierdirectlyto theloudspeaker outputs!
Do notconnectloudspeakersvia an external fader!
16
To prevent short-circuiting,
A
power supply connections (for 'ON/OFF LOGIC')
disconnect the negative
