Battery (not included)

The blower
with batteries from the POWER 21 V Line. The battery can be
removed in seconds and recharged using the Stocker 21 V charger.
Slide the battery into the battery compartment at the back of the
blower: slide it down until it 'clicks'. To remove it, press the two
buttons on either side of the battery and pull upwards.

Charger (not included)

1. Nominal voltage: ........................... .................................................... 100-240 V AC, 50-60 Hz
2. Output voltage: ......................................... .................... ..................... DC 21 V
3. Corrente di ricarica: ...................... ...................... ...............................1.4 A
4. Protection level: .................................. .............. ................................. II
56
Art. 630
Battery Blower 21 V

Assembly and use

does not have batteries included, and it is compatible
Art. 630
Battery Blower 21 V
Assembly and use

Use

Place the battery on the blower housing by sliding it downwards: if correctly positioned, it will emit a
‚click'. To disconnect the battery, press the two side buttons and slide upwards.
After pressing the power button, press the +/- button to increase the motor power. There are 5 power
levels in total. Press the +/- button to decrease the power level.
After turning on the device, press and hold the 'Turbo' button to start turbo mode. Release the button
to exit turbo mode and return to the previously set power level.
Switch off the device in the following situations:
- Whenever you leave it unattended;
- Before removing any obstructions;
- Before inspecting, cleaning or servicing the device;
- If it starts to vibrate abnormally.

Installing the air volume tube

Turn the tube button upwards, press it and insert the tube into the blower outlet along the guide until
it clicks into place.
For further information about the product, please contact info@stockergarden.com.
