• Donotmodify theproduct i nanyway.Doingsovoidsthewarranty
Warning
• Onlyconnect the product t o asocket t hat hasbeenapproved f orthedevice. T he
electrica
l
socket m ustalways be easily accessible
• Donotcontinue to operate thedevice if it becomes v isibly damaged(This ismandatory
for all products with220Vmainsconnections.)
4. Getting Started and Operation
• Connec
t
the power s upplyunitcablewiththeconnection socket(1)OftheQicharging
plate
• Connec
t
the power s uppyunitwithan approved e lectrical socket t o activate theQi
charging plate
• Theactive electric power s upplyis indicated bytheshortglowof thegreenLEDcollar (4)
around theQi charging plate
• Thepermanent glowOfthered (2)andgreen(3)status LEDs indicates thestandby O f
theQicharging plate
• Paceyourterminal d evice backside d ownon theQicharging plate(B)
Note
• Forcharging a terminal d evice withtheQicharging plate,yourterminal d evice hasto
beQicompatible. Please r eadtheoperating instructions o f yourdevice
• Pleasenote that mobile phone sleeves, c overs,etc and other materials betweenthe Qi
charging plateandthebackside o f yourterminal d evice disturborprevent a ctually the
charging process
• Thecharging process s tarts assoonasaninduction fied issuccessful y established The
red status LED(2)switches o ff,thegreen LEDcollar (4)gowsupshortly andthe
green status LED(1)starts to flashpermanently Y ourterminal d evice shows thecurrent
charging state
f thecharging process d oesnotstart,change theposition of yourterminal device to getan
induction connection
• f theterminal d evice battery is fuly oaded, t hecharging process s tops automaticaly The
greenstatus LED(3)andthegreenLEDcollar (4)glowaternately.
• Remov
e
yourterminal d evice fromtheQicharging plate Disconnect thepower s uppyunit
fromthegrid
3
