Quick-Loading Core Chucks
LABELMATE's precision, maintenance-free "Quick Chuck"™ Core Chucks support the mounting or
removing a roll of labels on your rewinder or unwinder in seconds. For applications with heavy label
rolls, regular roll changes and for holding multiple cores during slitting operations.
Fast loading & unloading
5 diameters available
3 widths, up to 270mm
Fit onto 15.85mm diameter
motor shaft
Limited Warranty
P/N
LMX479
LMX480
LMX481
LMX482
LMX483
LMX484
LMX485
LMX506 220mm outer Flange for "Quick-Chuck" 76mm core diameter.
LMX144 220mm inner Flange for "Quick-Chuck" 70 & 76mm core diameter.
LMX507 220mm inner Flange for "Quick-Chuck" 38, 40 & 44mm core diameter.
LMX508 300mm outer Flange for "Quick-Chuck" 76mm core diameter.
LMX509 300mm inner Flange for "Quick-Chuck" 70 & 76mm core diameter.
LMX510 400mm outer Flange for "Quick-Chuck" 76mm core diameter.
LMX511 400mm outer Flange for "Quick-Chuck" 76mm core diameter.
LMX512 400mm inner Flange "Quick-Chuck" 76mm core diameter.
LMX513 400mm inner Flange for "Quick-Chuck" 38, 40 & 44mm core diameter.
HOW TO:
• To use a Quick-Chuck, just slide your label roll over the Chuck and turn the convenient lock knob. Instantly your roll is
locked in place. To remove the roll, just give the lock knob a quick turn to the left and pull the roll off your machine !
GENERAL
• Limited Warranty of 2 Years, extendable to 5 Years, 1 Year on the Power Supply
MODEL
C-38170
C-40170
C-44170
C-70170
C-76170
C-76220
C-76270
DIAMETER
38 mm
40 mm
44 mm
70 mm
76 mm
76 mm
76 mm
WIDTH
170 mm
170 mm
170 mm
170 mm
170 mm
220 mm
270 mm
