4.6 Installing the Battery

4.6.1 Wall-mounted/Floor-mounted

1) Choose and mark appropriate locations on the wall for drilling holes with a positioning cardboard. It is
noted that when carrying out the floor installation, only positions of five holes at the top of the
positioning paperboard need to be marked.
Wall
Wall
Ground
How to differ the floor-mounted installation from the wall-mounted installation mainly depends on the
clearance L between the ground and the positioning cardboard.
Installation mode Clearance (mm)
Wall-mounted L ≥300
Floor-mounted L=0
