2.3.3 SE-F12-C

Status of Charge
(SOC)
Condition
Normal
Abnormal
Upgrade
Others
After initialized successfully, the LCD screen will be on
for long time and shows the SOC in percentage.
The screen stays on unless shutdown and dormancy.
The backlight in the shape of Deye appears blue.
If the fault in the next table occurs, the corresponding
fault code will be displayed on the LCD screen. For
details, refer to the next table.The backlight in the
shape of Deye appears red.
When upgrading, the screen will be filled with the
"upd" as well as the upgrade process in percentage.
The backlight in the shape of Deye appears blue.
1. The Deye backlight displays red and flash quickly
when there is a communication failure between the
LCD screen and the BMS motherboard.
2. The Deye backlight displays red while the system is
upgrading with faults existing.
10
Performance
Backlight
Error Code
