Bosch GTS 10 XC Professional Originalbetriebsanleitung Seite 33

OBJ_BUCH-1375-002.book Page 33 Monday, August 29, 2011 5:05 PM
Technical Data
Table saw
Article number
Rated power input
No-load speed
Reduced starting current
Run-on Brake
Overload Protection
Weight according to EPTA-Procedure 01/2003
Protection class
Dimensions (incl. removable product features)
Width x depth x height
Maximum workpiece dimensions, see page 38.
The values given are valid for a nominal voltage [U] of 230 V. For different voltages and models for specific countries, these values can vary.
Please observe the article number on the type plate of your machine. The trade names of the individual machines may vary.
Dimension of suitable saw blades
Saw blade diameter
Blade body thickness
Tooth thickness/setting, min.
Mounting hole diameter
Noise Information
Measured sound values determined according to EN 61029.
Typically the A-weighted noise levels of the product are:
Sound pressure level 98 dB(A); Sound power level
111 dB(A). Uncertainty K =3 dB.
Wear hearing protection!
Declaration of Conformity
We declare under our sole responsibility that the product de-
scribed under "Technical Data" is in conformity with the fol-
lowing standards or standardization documents: EN 61029
according to the provisions of the directives 2011/65/EU,
2004/108/EC, 2006/42/EC.
EC Type Certification No. MSR 1035 by notified testing agen-
cy No. 0366.
Technical file (2006/42/EC) at:
Robert Bosch GmbH, Dept. PT/ETM9,
D-70745 Leinfelden-Echterdingen
Dr. Egbert Schneider Dr. Eckerhard Strötgen
Senior Vice President Engineering Director
Engineering PT/ESI
Robert Bosch GmbH, Power Tools Division
D-70745 Leinfelden-Echterdingen
Leinfelden, 30.08.2011
Bosch Power Tools
3 601 L30 400
3 601 L30 440
3 601 L30 470
3 601 L30 490
3 601 L30 4P0
3 601 L30 4R0
W
-1
min
kg
mm 775 x 768 x 343
Assembly
mm 254
Avoid unintentional starting of the machine. During as-
sembly and for all work on the machine, the power plug
mm 1.8
must not be connected to the mains supply.
mm 2.6
mm 30
Delivery Scope
– Table saw with mounted saw blade 32 and riving knife 7
– Angle stop 3
– Profile rail 34
– Fastening kit "profile rail" 52 (guide plate, knurled nut,
screw, washer)
– Parallel guide 8
– Auxiliary parallel guide 49
– "Auxiliary parallel guide" fastening kit 39 (3 fastening
screws, 3 washers, 3 wing nuts)
– Blade guard 5.x*
* depending on country version: 5.1/5.2
– Table extension 10
– Fastening kit for "table extension" 43
(2 fastening screws, 2 washers, 1 open-end spanner)
– Allen key 37
– Ring spanner 15
– Cover of the saw blade storage 14
– Push stick 13
– Insert plate 31
English | 33
GTS 10 XC Professional
3 601 L30 460 3 601 L30 430
2100 1650
3200 4200
35 35
/II /II
775 x 768 x 343 775 x 768 x 343
Please also observe the representation of the
delivery scope at the beginning of the operat-
ing instructions.
Before starting the operation of the machine
for the first time, check if all parts listed below
have been supplied:
1 619 929 K16 | (29.8.11)
2000
4200
35
/II
