1.10 Specification
Models
Input Voltage
Input Frequency
Input Current
Input Cable
Input Protection
Charge Characteristic*
Output Voltage*
Output Cable
Output Current*
Output Protection
IP Rating
Cooling
Ventilation
Ambient temperature
User Interface
* Factory set as ordered, stated on rating plate
SP3 / SP3+
1PH - 230VAC  10% ONLY
45 – 66Hz
Model dependant - Specified on charger rating plate
2 meters of flexible PVC cable to BS6500 with 2 pin Euro or 3
pin UK plug fitted
Non-replaceable fuse inside
Microprocessor controlled –
S, D, L, M, U
Model dependent - 12, 24, 36, or 48V
2.9 meters of heat, oil resistant & flame-retardant cable to
BS6195
Model dependant - 0 to 60A
Replaceable fuse inside the cubicle
IP20
Forced cooling during charging
Chargers must be positioned with at least 100mm of clearance
at each end
0 – 35°C
Single RGB LED and one push button
