• The rating is suitable for the intended input supply and battery (lead-acid (vented, gel,
AGM) or lithium-ion) to be charged.
• The connector polarity is correct and matches the polarity of the battery connector.
Input supply
The input current rating and voltage of the charger is stated on the charger rating
plate.
The rating of the protection device should be based on the maximum input current, as stated
on this plate.
1.4 Display and Control
1.4.1 Overview
The user interface is located near the AC and DC outlet of the charger. It consists of:
1. 14-pin connector for Service
2. USB-connector for Service (optional)
3. RGB-LED for function signals
4. Button to start/stop charging and additional functions
1.4.2 Charge Status Indicator Summary
Mode
Bulk Charge
Second Stage
Charge Complete
Reset
Auto-balance / Refresh
Fault / Warning
Equalise
Pause
Standby
1.5 Operation
Before connecting the battery, check that the battery voltage corresponds to the vol-
tage indicated on the charger rating plate.
Indication
Yellow flashing
Yellow / green alternating
Constant green
Red Green Blue sequence
Green blinking
Red flashes indicating an error
code, followed by green
Green blinking
Light blue flashing
Constant light blue
