Commissioning
Automatic learning mo dus
To start the automatic learning mode, press
◆
the button.
Starting with the turnout output, the decoder
◆
waits in learning mode for the next command
from the central unit and assigns the address to
the turnout output.
For confirmation, the command received is
◆
also executed, i.e. a
connected point machine is switched.
After the first command received, the lantern
◆
output is automatically selected and the next
address is waited for again
If an address has been assigned to both
◆
outputs in this way, programming mode
ends
automaticall
y.
Assign address
If no command is received within 60 seconds
◆
or if the button is pressed again, the
learning mode is ended.
If the turnout output is to be skipped during
◆
addressing and only the address for the
lantern output is to be set, then
the button can be pressed again.
Address
Individual addresses can be assigned to the
◆
outputs. The addresses are free
selectable.
Careful
The decoder requires an address for the
◆
lantern output.
For example, all lanterns can be
◆
switched simultaneously.
