Commissioning
Example
An address should be assigned to each output:
Press the button on the decoder.
◆
The decoder starts with the points output and
◆
waits for the next command.
Execute a switch command at the control center,
◆
e.g. switch 22 to red.
The decoder receives the command and
◆
assigns address 22 to the turnout output
The decoder switches the points output to red.
◆
Example
The address of the lamppost exit is to be changed:
Press the button on the decoder
◆
The decoder starts with the points output and
◆
waits for the next command
Press the button again
◆
The decoder skips the points output and
◆
switches to the lantern output
The decoder waits for the next command
◆
Assign address
The decoder switches to the lantern output
◆
and waits for the next command.
The decoder receives the command and
◆
assigns address 23 to the lantern output, for
example.
The decoder switches the lantern output to red.
◆
The decoder exits the learning mode.
◆
Execute a switch command at the control center,
◆
e.g. switch 15 to red.
The decoder receives the command and
◆
assigns address 15 to the lantern output.
The decoder switches the lantern output to red.
◆
The decoder exits the learning mode
◆
