Technical data
7.1 Device Data
7.1 Device Data
Housing
Dimensions
Weight
Degree of protection
Screw Torque
Terminal screws
Grounding screw
Supply Voltage via a Wide-Range Power Supply Unit
Auxiliary voltage – direct voltage
Permissible voltage range
Current consumption
Power consumption
Ripple voltage in accordance with IEC 61000-4-17,
Peak-peak
Bridging time in the event of an outage or short circuit of the auxiliary voltage according to IEC 61000-4-29,
Auxiliary voltage V ≥ 60 V
Auxiliary voltage V ≥ 24 V to 60 V
Auxiliary voltage – alternating voltage
Permissible voltage range
Current consumption
Power consumption
Bridging time in the event of an outage or short circuit of the auxiliary voltage according to IEC 61000-4-29,
Auxiliary voltage V ≥ 110 V
Signal Relay (Life Contact)
Contact
Switching power
ON
OFF
Contact voltage
Permissible current
Not suitable for isolating supply voltages
44
Housing
Interfaces
0.4 Nm to 0.5 Nm
1.2 Nm
DC 24 V to 250 V
DC 19 V to 300 V
Max. DC 175 mA
Max. DC 3.5 W
≤12 % at the rated voltage
≥50 ms
t ≥ 40 ms
AC 110 V to 230 V, 45 Hz to 65 Hz
92 V to 286 V AC
Max. AC 100 mA
Max. AC 11 VA
t ≥ 50 ms
1 change-over contact
1000 W, 1000 VA
40 W, 30 VA inductive
250 V
5 A continuously,
30 A for 0.5 s
SIPROTEC 5, 7XV5461 Long Distance Fiber Optic Repeater, Manual
188 mm × 138 mm × 70 mm (W × D × H)
Figure 8-1
Approx. 0.8 kg
As per EN 60529
IP 41
IP 2x
C53000-G5050-C095-1, Edition 10.2024
