Product Features

The numbering of the product features refers to
the illustration of the sawing station on the
graphics pages.
1 Base unit
2 Scale for mitre angle (horizontal)
3 Locking knob for height adjustment
4 Guide rail with sawing slot
5 Side stops of the guide rail
6 Support extension
7 Additional support
8 Bridge
9 End stop for bevel cuts
10 Locking lever of the guide rail
11 Alignment mark
12 Locking knob for various mitre angles
(horizontal)
13 Angle indicator (horizontal)
14 Screw for angle indicator (horizontal)

Technical Data

Sawing station
Article number
Max. cutting length for
crossway cuts (90°)
Max. cutting height
Mitre/Bevel Angle
Horizontal
Vertical
Weight according to
EPTA-Procedure 01/2003
Dimension of suitable saw blades
Max. overall length
Max. toothed length
Only use the saw blades recommended by
Bosch (see page 76). When using saw blades
that are too thin, danger is given that the cut
runs out of centre.
1 609 929 S38 | (15.9.09)
PLS 300
3 603 M04 0..
mm 315
mm 25
° ± 45
° ± 45
kg 3.2
mm 100
mm 76
Operation

Preparing for Operation

The saw station must be assembled depending
on the respective sawing application:
– Sawing Panels
(e. g. laminate flooring panels)
– Sawing Profiles
(e. g. baseboards)
The use of screws/bolts is not required.
Sawing Panels (cross section)
(see figures A1 – A3)
– Mount the support extensions 6 left and right
to the base unit 1.
– Depending on the workpiece size, mount the
additional supports 7 to the inner or outer
guide of the support extensions.
– Loosen the locking knob 3 a few turns.
– Turn the locking lever 10 of the guide rail left-
ward and fold the guide rail 4 upward.
– Mark the desired cutting line on the work-
piece.
– Place down the workpiece with the visible
side flat against the stop of the base unit 1.
– Fold the guide rail downward and align the
workpiece to the cutting line of mark 11.
– Lock the guide rail with lever 10.
– Tighten the locking knob 3.
Sawing Panels (mitre cuts) (see figure B)
The horizontal mitre angle can be set in the
range from 45° (left side) to 45° (right side).
– Loosen locking knob 12.
– Turn the guide rail 4 left or right until the an-
gle indicator 13 indicates the requested mi-
tre angle.
– Tighten the locking knob 12 again.
For swift and precise adjustment of standard
mitre angles, the guide rail engages at 0° and
45°.
– For additional worksteps, see "Sawing Pan-
els (cross section)" on page 14.
