EN
Ⅳ . How to install
Free standing installation:
First, take the heater out the package and place it upside down on soft surface.
Second, take four screws from the accessories(two screw for each castor, parallel
the bevel of castor bracket to the bevel of the heater, if installed reversely, the screw
cannot be revolved in.)and aim them at the taps to tighten them.
Third, Then just upright the heater and put it into use. You may refer to the following
figure.
OPERATION
1. Room temperature can be adjusted using the thermostat. Simply turn the
thermostat knob clockwise, to increase the heater, and anti-clockwise to decrease
the temperature, until you reach the desired temperature.
2. Switch the heater to one of the following power settings.
HY-200C: Push switch one (I) for 1000W
Push switch two (II) for 2000W
3. The power switch lights up when activated.
4. Turning the thermostat control clockwise will increase the "set" temperature.
5. Turning the thermostat anti-clockwise will decrease the "set" temperature.
6. Do not cover the heater at any time during operation. There is a risk of fire if the
heater is covered.
7. Once you have finished using your heater, turn the power switches off, and the
thermostat control switch to the "Low" positions, and unplug from the mains supply.
3
