TECHNICAL DRAWING

SPARE PARTS LIST

Front grid
Blades
Plas c nut
Motor
Upper flexible hose
Control bu ons
Power cord
Base and base cover
Water tank cover
Water tank indicator
Blade spinner
Net frame
Rear grid
Low flexible hose
Func on indicators
Bolts
Suppor ng tubes
Mist Vent (Fixed on the front grid)
Water tank
Mist generator
