Operation

Detection of phase voltage, leakage voltage and display

of the RCD tripping current:

After you have plugged the tester into a standard socket. You

can read the phase voltage (L_N), the arrester voltage (N_E)

and the RCD tripping current on the tester's display.

Warning:

If the socket is not connected correctly, the leakage

voltage cannot be measured.

RCD test:

Plug the test device into the correctly connected socket and the

tripping current of the RCD will be shown on the display. Press

and hold the RCD button for more than 2 seconds, then the nor-

mal RCD will trip and the trip time will be displayed and the but-

ton indicator will flash to show that tripping is complete. If it

does not trip, it indicates that the RCD has failed. After the

measurement, press the RCD button (approx. 1 second) to re-

turn to the mains sequence measurement interface.

RCD:

If the triggering time is more than 100 ms, the screen turns or-

ange and "ERR" is displayed.
