4. Remove the protective film from the other side of the adhesive strip
5. Align the device horizontally in the desired position and press firmly
5.3 Technical data
Type
Dimension
Weight
Ambient temperature
Ambient humidity
Storage temperature
Operating voltage
Battery type
Radio frequency
Type: Free-field radio range
Max. Radiated power
Protection type
The maximum possible radio range within buildings depends on
the individual environmental factors on site. The actual radio
range may differ greatly from the free-field radio range.
RLDS 61071-N6
86 × 58 × 20.6 mm
183 g
0 ... 50 °C
5 ... 80 %, not condensing
-10 ... +50 °C
3 V d.c.
2× 1.5 V LR06/AA (Mignon) Alkaline
868.3 and 869.525 MHz SRD band
270 m
≤ 25 mW
IP 20
