Frontier™ 5000 Series Multi
FC5707
Clean the drive shaft with a clean, grease-free piece of cloth (see Figure 4).
Place the rotor onto the drive shaft and hold the rotor with one hand and tighten the fixing nut by hand (see Figure
8).
Motor shaft and chamber
Figure 7
ATTENTION!
Check that the fixing screw and fixing nut is properly installed before each run (see figures 6 and 8).
Do not operate the centrifuge with rotors or buckets which show any signs of corrosion or mechanical
damage.
Do not operate with extremely corrosive substances, which could damage the rotor, buckets, and
materials.
In case of any questions, please contact the manufacturer!
3.4.3 Change rotor ID / type of rotor (only FC5706P)
Before the first operation and after each rotor change, you have to set the rotor ID. You find each rotor type in the
printed order number on the rotor.
Example:
Angle rotor order number:
30130877 Rotor Type on the
display = 77
Turn on the centrifuge and open the lid. Now simultaneously press the keys "Quick Spin"(6) and "Stop/Lid"(7).
In the display "RPM/RCF" the current rotor ID appears as well as the word "CHOSE". With the touch wheel (1)
you can now set the needed rotor ID. To store the new setting please press the "Store"(10) or "Start" (8) key.
Inside the display, "Store" appears as confirmation.
With that, all rotor specific data, like max. speed, acceleration etc., are adopted.
Fixing nut
Figure 8
EN-12
