Press the
Select Exit to close the Menu.
When powered-up, the PosiTector automatically
determines which probe is attached and does a
self-check.
To disconnect a probe from a body, slide the plastic
probe connector horizontally (in the direction of the
arrow) away from the body. Reverse these steps to
attach a different probe. It is not necessary to
power-down the Gage when switching probes.
PosiTector SPG and SPG S probes include a 60˚ (ASTM D
4417 B) or 30˚ (Australian Standard AS 3894.5) angle tip (50
μm/2 mil radius) with a measurement range of 0 to 500 μm (20
mils).
PosiTector SPG OS probes have the same specifications as
the PosiTector SPG probes above but feature a V-groove
sleeve ideal for measuring flat or convex surfaces such as tanks
and pipes.
PosiTector SPG CS probes measure the profile of textured
coatings up to 1500 μm (60 mils) with a 500 μm (20 mil) radius
60˚ angle tip.
button or swipe right to return to a previous screen.
When a Menu option is highlighted, the
icon indicates on-gage help is available.
Press
help. A formatted PDF containing all on-
gage help items is available at
www.defelsko.com/help
NOTE:
you have the latest on-gage help infor-
mation.
indicates that a sub-menu exists for the
Menu option. Select the option to display
its sub-menu.
or touch the
Update your gage to ensure that
Probes
2
icon to display the
