TECHNICAL DATA
MODEL
Speed*
Torque
Max. working cycle
Control unit
Power
Motor power
Consumption
Maximum power
Capacitor
Thermoprotection
Protection degree
Product dimensions
(L - P- H)
Product weight
Working temperature
Max gate weight
Sound emission level
TECHNICAL DATA
MODEL
Speed*
Torque
Max. working cycle
Control unit
Power
Motor Power
Consumption
Maximum power
Capacitor
Thermoprotection
Protection degree
Product dimensions
(L - P- H)
Product weight
Working temperature
Max gate weight
Sound emission level
* Variable data according to gate weight
** Cycles/hour referring to a standard leaf with a length of 4m and weight of 200Kg, evaluated at an ambient temperature of 20°C.
For leaves longer than 4m the maximum number of cycles/hour must be reduced proportionally (for example, for 8m leaves the maxi-
mum number of cycles/hour must be reduced by 50%).
For environmental temperatures above 20°C the maximum number of cycles/hour will be reduced by 15% for every 5°C increase in
temperature (for example, for an environmental temperature of 30°C the maximum number of cycles/hour will be reduced by 30%).
For doors whose weight corresponds to the maximum use limit for that type of product, the maximum number of cycles/hour will be
reduced by 50%.
6
TUS92M
cm/s 16
Nm 29
Cycles/hour 20
Mod. CT102B
230 Vac 50/60 Hz
230 Vac
A 2
W 450
µF 16
°C 150
IP 44
mm 335 - 190 - 280
kg 9,8
°C -20 +55
kg 900
dB(A) ≤ 70
TUS122M
cm/s 16
Nm 35
Cycles/hour 20
Mod. CT102B
230 Vac 50/60 Hz
230 Vac
A 2,6
W 600
µF 20
°C 150
IP 44
mm 335 - 190 - 280
kg 10,8
°C -20 +55
kg 1200
dB(A) ≤ 70
TUS8324 TUS120
25
26
40
CT10324
230 Vac 50/60 Hz 230 Vac 50/60 Hz
24 Vdc 230 Vac
1,5
345
-
-
44
335 - 190 - 280 335 - 190 - 280
8,5
-20 +55 -20 +55
800
≤ 70
TUS12324 TUS162
20
38
50
CT10324 CT102B
230 Vac 50/60 Hz 230 Vac 50/60 Hz
24 Vdc 230 Vac
1,3
300
-
-
44
335 - 190 - 280 335 - 190 - 280
8,8
-20 +55 -20 +55
1200
≤ 70
TUS122
16 16
35 35
20 20
- CT102B
230 Vac 50/60 Hz
230 Vac
2,6 2,6
600 600
20 20
150 150
44 44
335 - 190 - 280
10,8 10,8
-20 +55
1200 1200
≤ 70 ≤ 70
16
40
20
3
700
20
150
44
11,5
1600
≤ 70
