2 - PRODUCT OVERVIEW
2.1 - Product description
Irreversible electromechanical gearmotor for sliding gates operating at 24 Vdc and 230 Vac. (Fig.1)
2.2 - Model and technical characteristics
CODE DESCRIPTION
TUS60 230 Vac gear motor with mechanical limit switches, gate maximum weight 600 kg, without control unit
TUS62 230 Vac gear motor with mechanical limit switches, gate maximum weight 600 kg
TUS62M 230 Vac gear motor with magnetic limit switches, gate maximum weight 600 kg
TUS4324
24 Vdc gear motor with mechanical limit switches, gate maximum weight 400 kg
TUS5324F 24 Vdc gear motor with magnetic limit switches, gate maximum weight 500 kg, Fastline
TUS6324 24 Vdc gear motor with mechanical limit switches, gate maximum weight 600 kg
TUS90 230 Vac gear motor with mechanical limit switches, gate maximum weight 900 kg, without control unit
TUS92
230 Vac gear motor with mechanical limit switches, gate maximum weight 900 kg
TUS92M 230 Vac gear motor with magnetic limit switches, gate maximum weight 900 kg
TUS8324 24 Vdc gear motor with mechanical limit switches, gate maximum weight 800 kg
TUS120 230 Vac gear motor with mechanical limit switches, gate maximum weight 1200 kg, without control unit
TUS122
230 Vac gear motor with mechanical limit switches, gate maximum weight 1200 kg
TUS122M 230 Vac gear motor with magnetic limit switches, gate maximum weight 1200 kg
TUS12324 24 Vdc gear motor with mechanical limit switches, gate maximum weight 1200 kg
TUS162 230 Vac gear motor with mechanical limit switches, gate maximum weight 1600 kg
TECHNICAL DATA
MODEL
Speed*
Torque
Max working cycle** Cycles/hour
Control unit
Power
Motor power
Consumption
Maximum power
Capacitor
Thermoprotection
Protection degree
Product dimensions (L - P- H)
Product weight
Working temperature
Max gate weight
Sound emission level
TECHNICAL DATA
MODEL
Speed*
Torque
Max working cycle** Cycles/hour
Control unit
Power
Motor power
Consumption
Maximum power
Capacitor
Thermoprotection
Protection degree
Product dimensions (L - P- H)
Product weight
Working temperature
Max gate weight
Sound emission level
TUS60
cm/s 16
Nm 16
20
Mod. -
230 Vac 50/60 Hz
230 Vac
A 1,7
W 380
µF 12,5
°C 150
IP 44
mm 335 - 190 - 280
kg 9,1
°C -20 +55
kg 600
dB(A) ≤ 70
TUS5324F
cm/s 40
Nm 23
40
Mod. CT10324
230 Vac 50/60 Hz
24 Vdc
A 1,3
W 300
µF -
°C -
IP 44
mm 335 - 190 - 280
kg 8,5
°C -20 +55
kg 500
dB(A) ≤ 70
TUS62 TUS62M
16
16
20
CT102B CT102B
230 Vac 50/60 Hz 230 Vac 50/60 Hz
230 Vac 230 Vac
1,7
380
12,5
150
44
335 - 190 - 280 335 - 190 - 280
9,1
-20 +55 -20 +55
600
≤ 70
TUS6324 TUS90
24
18
40
CT10324
230 Vac 50/60 Hz 230 Vac 50/60 Hz
24 Vdc 230 Vac
1,2
250
-
-
44
335 - 190 - 280 335 - 190 - 280
8
-20 +55 -20 +55
600
≤ 70
TUS4324
16 24
16 12
20 40
CT10324
230 Vac 50/60 Hz
24 Vdc
1,7 1,1
380 250
12,5 -
150 -
44 44
335 - 190 - 280
9,1 7
-20 +55
600 400
≤ 70 ≤ 70
TUS92
16 16
29 29
20 20
- CT102B
230 Vac 50/60 Hz
230 Vac
2 2
450 450
16 16
150 150
44 44
335 - 190 - 280
9,8 9,8
-20 +55
900 900
≤ 70 ≤ 70
