FUMES DISCHARGE
HOOD WITH INTERNAL RECIRCULATION (FILTERING)
In this model, air passes through the carbon and zeolite filters
to be purified and is then recycled into the environment.
Ensure that the zeolite filters are assembled into the hood, if
not, install them as indicated in the assembly instructions.
ASSEMBLY INSTRUCTIONS
only intended for personnel qualified
The hood can be installed in various configurations.
The generic assembly steps apply to all installations; for each case,
follow the specific steps provided for the required installation.
OPERATION
WHEN TO TURN ON THE HOOD?
Switch on the hood at least one minute before starting to cook to direct fumes
and vapours towards the suction surface.
After cooking, leave the hood operating until complete extraction of all vapours
and odours. By means of the Timer function, it is possible to set auto switch-off
function which will allow the hood to turn off automatically after 15 minutes of
operation.
WHICH SPEED IS TO BE SELECTED?
1st speed: maintains the circulation of clean air with low electricity consump-
tion.
2nd speed: normal conditions of use.
3rd speed: presence of strong odours and vapours.
4th speed: rapid disposal of odours and vapours.
With a view to reducing environmental impact, it is suggested to always set the
minimum speed suitable for the required suction level.
WHEN SHOULD THE FILTERS BE WASHED OR REPLACED?
The metal filters must be cleaned every 30 hours of operation.
For further details see the "MAINTENANCE" chap.
ROTARY CONTROL - FUNCTIONS
OFF
(DAMA - SOFFIO)
PUSH
OFF Motor OFF
I speed 1 (green light)
I I speed 2 (blu light)
I I I speed 3 (violet light)
speed 4 (red light). It is activated by pressing the button
PUSH
2 seconds. After a few minutes it comes back ti speed 3.
Pressing for a second:
On / off light
TIMER (can only be activated by remote control)
(flashing)
Auto switch-off after 15 min.
The function deactivates (LED off ) if:
The TIMER key is pressed again or motor OFF.
FILTER ALARM (LED steady on with OFF )
Anti-grease filter maintenance after approximately 30 hours of op-
eration.
Press for 4 seconds to reset.
ROTARY CONTROL - FUNCTIONS
OFF
OFF Motor OFF
I speed 1 (green light)
I I speed 2 (blu light)
I I I speed 3 (violet light)
speed 4 (red light). It is activated by pressing the button
PUSH
2 seconds. After a few minutes it comes back ti speed 3.
Light on/off
Short impulse: turn light on and off
Long impulse (MOTOR OFF): change light tone from 2700K to
5600K
TIMER (can only be activated by remote control)
(flashing)
Auto switch-off after 15 min.
The function deactivates (LED off ) if:
The TIMER key is pressed again or motor OFF.
FILTER ALARM (LED steady on with OFF )
Anti-grease filter maintenance after approximately 30 hours of op-
eration.
Press for 4 seconds to reset.
20
for
(SOPHIE - VOGUE)
PUSH
for
