Start-up and parameter settings

Using SOPAS ET to modify display settings

4.3.4
To modify factory settings, select device "MCU" in the "Project Tree" window, enter the level
1 password and select the "Configuration / Display Settings" directory.
Figure 24 "Configuration / Display Settings" directory
Window Entry field
Common Display Display Language
Settings
Display Unit System Unit of measurement system used in displays
Overview Screen Bar 1 to 8
Settings
Value
Use AO scaling
Limit low
Limit High
90
O P E R A T I N G I N S T R U C T I O N S
8029861/AE00/V0-2/2012-12
Significance
Language version shown on the LC-Display
Sensor address for the first measured value bar in the graphic display
Measured value index for the respective measured value bar
When activated, the measured value bar is scaled to the associated analog output.
If not activated, define the limit values separately
Values for separate scaling of the measured value bar independent of the analog
output
