• Avoid mowing in places where the wheels have
trouble gripping or mowing is unsafe in any other
way. Before you back up, ensure that nobody is
standing behind you (especially little children, who
are more difficult to see).
• When mowing over thick, high grass, select the
highest cutting level and mow at a slower speed.
Before you remove any grass or blockages of any
kind, switch off the engine and pull the plug boot.
• Never remove any safety-related parts.
• Never fill the engine with petrol when it is hot or is
running.
Emptying the grass basket
As soon as grass clippings start to trail the lawn mow-
er, it is time to empty the grass basket.
m WARNING
Before taking off the grass basket, switch off the
engine and wait until the blade has come to a
stop.
To take off the grass basket (16), use one hand to
lift up the chute flap (15) and the other to grab onto
the basket handle (Fig. 16). Remove the basket. For
safety reasons, the chute flap (15) automatically falls
down after removing the grass basket and closes off
the rear chute opening.
If any grass remains in the opening, it will be easier to
restart the engine if you pull the mower back approx.
1 meter.
Do not use your hands or feet to remove clippings
in or on the mower housing, but instead use suitable
tools such as a brush or a hand broom.
In order to ensure that the majority of grass clippings
are picked up, the inside of both the grass basket (16)
and especially the air grill must be cleaned after each
use.
Reattach the grass basket (16) only when the engine
is switched off and the blade is stopped. Using one
hand, lift up the chute flap (15), while grabbing onto
the basket handle with the other. Hang in the basket
from the top. Fig. 9
After mowing
• Allow the engine to cool before you put the lawn
mower in an enclosed area.
Remove grass, foliage, grease and oil before stor-
ing the mower. Do not place any objects on top of
the mower.
• Check all the screws and nuts once more before
you start to use the lawn mower again. Tighten any
loose screws.
• Also be sure to empty the grass basket (16).
• Pull the spark plug boot to prevent unauthorized
use.
• Ensure that you do not park the mower next to any
source of danger. Petrol fumes can lead to explo-
sions.
• Only original parts or parts approved by the man-
ufacturer may be used for repairs (see address on
the warranty certificate).
• If the lawn mower is not going to be used for an ex-
tended period, empty the petrol tank using a petrol
suction pump.
• Oil and maintain the machine.
10. Cleaning
Warning!
Always shut the engine down and remove the spark
plug connector before carrying out any cleaning work.
The lawn mower should be thoroughly cleaned after
every use, especially the underneath and the blade
mount. To remove the gras, tip the lawn mower onto
its left side (the opposite side to the oil filling socket)
or clean the mower with water as descript below:
• Remove the mulch unit / gras box.
• Fit the hose connection to the mower (w) and turn
the tap on. (Fig. 24)
• Start the mower and switch off again after about 30
seconds. The rotating blade bar throws the water
onto the bottom of the mower and thus cleans it.
• Turn off the tap and remove the hose connection.
• Clean the top with a cloth (do not use any sharp
objects).
m Note! Before you tip the lawn mower onto its side,
completely empty the fuel tank using a petrol suction
pump. The lawn mower must never be tilted by more
than 90 degrees.
Dirt and grass is easiest to remove immediately after
you have finished mowing the grass. Dried on grass
and dirt can result in poorer mowing performance.
Check that the grass chute is free of any residual
grass. Remove any such residue.
Never clean the lawn mower with a water jet or
high-pressure cleaner. The engine must remain dry.
Do not use aggressive cleaning agents such as cold
cleaner or petroleum ether.
11. Transport
Preparing the mower for transportation (Fig. 22)
• Empty the petrol tank.
• Always let the engine run until it has used up the
remainder of petrol in the tank.
• Empty the engine oil from the warm engine.
• Remove the spark plug boot from the spark plug.
• Clean the cooling fins of the cylinder and the housing.
www.scheppach.com
GB | 37
