Names of Parts
USB Port 1
Connect the bus-powered USB devices (for example, CD/DVD drive) to the USB port 1.
Specifications
Item
Power Supply Input
Connector
USB Port*
1
2a / 2b / 2c
LAN Port
External Display Port
Physical Dimensions
(Width × Height × Depth)
Weight
Operating Environment
Temperature / Humidity
*
1
Does not guarantee operation of all USB-compatible peripherals.
ENGLISH
External Display Port
LAN Port
USB Ports 2a / 2b / 2c
Allowable current for each port : 100 mA
DC15.6 V (Use only the specified AC adaptor with your
computer.)
65-pin
USB x 4 (USB 2.0)
Allowable current for each port : 100 mA
IEEE 802.3 10 Base-T,
IEEE 802.3u 100 Base-TX (RJ-45)
IEEE 802.3ab 1000 Base-T
Mini Dsub 15-pin female
150 mm × 22 mm × 52 mm
{6.0" × 0.9" × 2.0"}
Approx. 225 g {0.5 lb.}
5 °C to 35 °C {41 °F to 95 °F} /
30 % to 80 % RH (no condensation)
DC-IN Jack
Description
