Technical specifications
Input voltage of the battery
Output voltage per socket / AC frequency
Permanent current / Input current
Output power
Output
waveform
Nominal load efficiency
USB output ports
AC output
Circuit protection (DC overload) 3x 40A internal fuses
Weight / Dimensions
Package Contents
Warnings & Caution
Use of the device in life support applications where failure of the device can
reasonably be expected to cause the failure of the life support equipment or to
significantly affect its safety or effectiveness is not recommended.
use the device in the presence of a flammable anesthetic mixture with air,
oxygen or nitrous oxide, and also not near flammable materials, fumes or
gases.
Since the device requires adequate ventilation during operation, do
not block fan or cooling vents and do not cover the device. Do not operate
near car heating vents or in direct sunlight.
and disconnect when not in use.
starting your engine. DO NOT plug a surge protector, line conditioner or UPS
system into the device. If you attach AC extension cords, use the heaviest
practical gauge.
manual to make sure that the technical specifications of the device (including
output waveform) fall within the recommendations of the external battery
charger or adapter.
MSW
The power inverter's MSW [Modified Sine Wave] is
especially suitable for light and heat with max. 1200W. MSW
output can produce "humming" when connected to audio
equipment and is generally unsuitable for sensitive electronics.
Power Inverter 1200W TE16, Fixed bracket on device,
2x 90cm connection cables, User Manual
Before connecting a battery charger or adapter, check its
DC 12V (10.5V–16V)
AC 230V / 50Hz nominal
115A / max. 125A
1200W (maximum, continuously)
2400W (peak)
90%
2x 5V USB ports with max. 3.1A (in total)
2x 230V safety contact sockets
2.3kg (with cables)
(L) 28.8 x (W) 15.9 x (H) 9.9cm
Keep the device dry at all times
Turn OFF connected equipment before (!)
Do not
