1.Before using your vacuum pump
In all cases,
motors are designed for operating voltages plus or minus 1 0 %
normal rating.
Single voltage motors are supplied fully connected and ready to
operate.
( 1 ) Check to be sure the voltage and frequency at the outlet match the specifica-
tions on the pump motor decal.
position before you plug the pump into an outlet. Remove and discard the exhaust
cap from the end of the pump' s handle.
( 2 ) The pump is shipped without oil in the reservoir. Before starting the pump,
it with oil. Remove the Exhaust Fitting cap and add oil until the oil just shows in the
bottom of the sight glass.
1 8 0 ~ 8 0 0 ml( reference the technical data) .
( 3 ) Replace the Exhaust Fitting cap and remove the cap from one of the inlet
ports.
Turn the motor switch to ON. When the pump runs smoothly,
on the inlet port.
temperature. After the pump runs for approximately one minute,
glass for the proper oil level.
line. Add oil if necessary.
Note:When the pump is running, the oil level should be even with the line on
the sight glass.
result in oil blowing from the exhaust.
PUMP COMPONENTS
OPERATING MANUAL
Check the ON- OFF switch to be sure it is in the OFF
The approximate oil capacity of the pump is
This may take from two to 3 0
The level should be even with the sight glass oil level
Underfilling will result in poor vacuum performance. Overfilling can
seconds,
- 3 -
replace the cap
depending on the ambient
check the sight
of the
fill
