4. Features
This basic home alarm system has an integrated PIR sensor and
camera. The PIR sensor detects if an intruder enters the room and
the camera starts recording video files. An infrared remote allows
you to arm and disarm the alarm system. A solar panel provides
power during standby. The battery power is only used during an
alarm trigger and video recording.
• alarm trigger: motion detection via PIR sensor
• remote control to arm and disarm the alarm system
• camera: record video files after a PIR trigger
• solar panel to extend battery lifetime
• 130 dB alarm sound
• mute mode: the alarm sound can be disabled
• quick and easy installation.
5. Overview
Refer to the illustrations on page 2 of this manual.
alarm system with camera
1 solar panel
2 IR LEDs for night vision
3 camera
4 indicator LED
5 motion detector
remote control
11 IR LED
12 indicator LED
6. Installation
6.1 Installing/Replacing Batteries
Refer to the illustrations on page 3–4 of this manual.
Warning! Do not puncture batteries or throw them in fire as
they may explode. Do not attempt to recharge non-
rechargeable batteries (alkaline). Dispose of batteries in
accordance with local regulations. Keep batteries away from
children.
V. 03 – 15/01/2018
HAM202
6 siren
7 USB port
8 microSD card slot
9 delete/mute button
10 battery compartment
13 arm button (ARM)
14 disarm button (CLR)
