2. Remove the alarm body from the wall and take out the
batteries.
3. Press and hold the Delete/Mute button [9] and place the
batteries back.
4. Then release the Delete/Mute button. The siren is now muted.
5. Place the alarm back on the wall.
When the siren is muted and video files have been recorded, the
LED [4] flashes to indicate that there are video files available. To
stop the LED from flashing, take the alarm from the wall and press
the Delete/Mute [9] button.
Viewing Recorded Video Files
To view recorded video files, proceed as follows:
1. Press the CLR button to disarm the alarm.
2. Connect the alarm to your pc via the USB port [7] and the
included USB cable.
3. On the pc, look for the removable drive that represents the
camera.
8. Troubleshooting
Problem: I installed the batteries, but the alarm did not beep.
Solution: Make sure that the batteries are installed correctly
according to the polarity markings in the battery compartment.
Problem: The alarm does not arm.
Solution: Make sure that the batteries are installed correctly; that
the cover is fixed in place correctly; and that the indicator LED [12]
on the remote control lights up when pressing the arm or disarm
buttons.
Problem: The red LED is on.
Solution: The batteries are low. Replace the batteries immediately.
9. Technical Specifications
power supply
PIR detection area 120° horizontal and 60° vertical
sound level
alarm delay
pick-up element
V. 03 – 15/01/2018
HAM202
solar panel
battery
130 dB
exit delay 30 seconds, entry delay 5 seconds
colour CMOS sensor
11
4.5 V
3 x 1.5 V AA batteries (not incl.)
