Figure 6. How to Link the Boots
Turn ON both boots. In Lead In Lead Boot, toggle down and select Link
boot, toggle down and select Boots. Follow the instructions and press
settings. the Support Boot Button 3 times quickly.
11. Charging the Device
1. The battery status of both boots is displayed on the top right corner of the control panel on the lead boot.
2. Plug one end of the power adapter into a wall outlet and connect the other end to the splitter.
3. Connect both cables on the splitter to the charging port on each boot. Lift the rubber cover located on the right side of each foot to access the charging ports.
4. The device can be used while charging, but the battery level may not increase while the device is in use. Turn off the device to expedite the charging process.
5. The control panel will display the battery icons with a bolt to indicate that the lead and/or support boot are charging. Note that the support boot also indicates its battery status using the color of the center light:
a. While not charging: >30% battery (white) and <30% battery (orange)
b. While charging: >90% battery (solid green if charging only, solid white if in use and charging) and <90% battery (flashing orange)
6. Battery life of the device:
a. Battery life on high use: 150 minutes
b. Battery life on low use: 240 minutes
**Note: If using an alternative power adapter or splitter cable, ensure that it is from a trusted source and has not suffered any structural damage. Previous RecoveryAir model's power adapter and splitter are not compatible with the device.
Connected
Support Boot Light Support Boot
Blinking Fast Light Solid
Lead and Support Boots will
link and connect automatically.
Repeat if unsuccessful.
Boot Status Description
Both boots are
powered ON but do
Unlinked not connect with each
other.
One of the boots is
OFF or outside the
Disconnected
connection range.
Both boots have
connected and ready
Connected
to use.
Lead JetBoot PRO Support JetBoot PRO
Plus Screen Plus Power Light
Blinking Fast
Blinking Slow
Solid White/
Orange
EN
11
