• Ceiling mounting
1. Attach the ceiling mounting positioning sticker on the desired installa-
tion location on the ceiling. Drill two holes at the positions indicated on the
sticker. The drilling diameter should be around 6.0 mm with a depth of
around 30 mm.
2. Insert two plastic expansion nuts into
the wall. Put the base plate on the ceiling.
Secure the base plate by inserting the
screws into the expansion nuts.
Note: The product must be hung
horizontally after installation (see
below).
• Pole mounting
Note: The product must be hung horizontally after installation (see below).
Notes on wall mounting:
1. The wall on which the device is mounted must have a loading capacity
of at least 3 times the weight of the device.
2. To avoid any damages or injuries, the device must be securely fastened
to the floor/wall as specified in the installation instructions.
