WARNING：To avoid danger of electric shock, unplug from outlet when not in
use and before cleaning. If the supply cord is damaged, it must be
replaced by the manufactory or it's service agent or a similarity
qualified person in order to avoid a hazard.
Parts Name
ASSEMBLY
1.Snap the two parts of the base together and secure with the four screws using
screwdriver.
2.Pass the Power Cord through the center hole of the base, after snapping the two pieces
together (The back piece is the one with the power cord securing channel).
3.Line up the Tower fan on the base. Fix with the 4 long screws, with a screw- driver. shown
in FIGURE 1.
Operation
The FAN may be operated by the manual controls located on the FAN (as shown in
–
FIGURE 2)
1.Place the FAN on a stable flat surface. Plug the cord set into a 220-240V~A.C. electrical
outlet.
2.Speed : Press '0' – Off, '1' – low fan speed, '2' – medium fan speed and '3' – High speed.
3.Oscillating : press the 'osc' button, then the unit will oscillate, if you want to stop the
oscillating, just press the 'osc' again.
Top control panel
Air outlet
Front housing
Base
(Figure 1)
(Figure 2)
3
