Specifications

2.1

Technical specifications PCE-LES303 Series.

Specification
Lamp 3 high power white
technology
Light colour cool white 6,200 K
Light power
Measurement
range
Resolution
Accuracy
Flash duration
range
Phase shift
Slow motion
Mode
External trigger
input
External trigger
output
Route
measurement
Display
Battery
Charging time
Operating time
PCE-LES 303 PCE-LES 303UV-365
3 high power UVA LEDs
LEDs
UVA light 365 ... 370 nm
11730 lx @ 20 cm
@ 1000 Hz, 1 %
6160 lx @ 30 cm
@ 1000 Hz, 1 %
2650 lx @ 50 cm
@ 1000 Hz, 1 %
60 ... 9999.99 FPM: 0.01 FPM
10,000 ... 300,000 FPM: 0.1 FPM
0.01 % ... 1 % of total flash duration
selectable speed from 1 to 99 RPM
permitted input: NPN signal, 24 V DC
sensor supply: 24 V / 100 mA for external sensors
open drain output, up to 24 V, 50 mA
up to 15 routes, 10 machines per route, 5 points per machine
programmable auto power off
conditions: flashing 100 Hz, 1 %, display brightness 70 %
© PCE Instruments
TBA
60 ... 300,000 FPM
1 ... 5,000 Hz
1 ... 5000 Hz: 0.01 Hz
0.001 % of setting
Resolution: 0.01 %
0.01 º ... 3.60 º of 360 º
Resolution: 0.01 º
... +360
o o
-360
o
Resolution: 1
2.8" TFT LCD
li-ion rechargeable battery
2200 mAh, 7.4 V
approx. 2 h 30 min
@ 5 V / 2 A
approx. 4 h 30 min
38
PCE-LES 303UV-385
3 high power UVA LEDs
UVA light 380 ... 390 nm
2
635 µW/cm @ 20 cm
@ 1000 Hz, 1 %
2
317 µW/cm @ 30 cm
@ 1000 Hz, 1 %
2
115 µW/cm @ 50 cm
@ 1000 Hz, 1 %
