lock
Operating lock (activation/deactivation only
via Alpha Smart App)
Temperature outside the display range
Actual temperature exceeded,
in conjunction with:
Actual temperature undershot,
in conjunction with:
Error, service
No bootable firmware recognised,
contact service
Error, temperature
Sensor error detected,
in conjunction with:
The setpoint temperature (min./max.) is limited in
the Alpha Smart app:
–
5 ... 30
–
0: deactivated (default)
8.1
Floor sensor
The installation of an optional connection set offers the fol-
lowing possibilities:
– Installation as a floor sensor
– Installation as room sensor
– Installation of a dew point sensor
See User information Connection set with external sen-
sor for Alpha Smartware room control unit (AT 61201-N)
Adjustable values floor sensor:
1,0 18.0
3,6 23.2
1,2 18.4
3,8 23.6
1,4 18.8
4,0 24.0
1,6 19.2
4,2 24.4
1,8 19.6
4,4 24.8
2,0 20.0
4,6 25.2
2,2 20.4
4,8 25.6
2,4 20.8
5,0 26.0
2,6 21.2
5,2 26.4
2,8 21.6
5,4 26.8
3,0 22.0
5,6 27.2
3,2 22.4
5,8 27.6
3,4 22.8
6,0 28.0
7,0 30.0
9,6 35.2
7,2 30.4
9,8 35.6
7,4 30.8
10,0 36.0
7,6 31.2
10,2 36.4
7,8 31.6
10,4 36.8
8,0 32.0
10,6 37.2
8,2 32.4
10,8 37.6
8,4 32.8
11,0 38.0
8,6 33.2
11,2 38.4
8,8 33.6
11,4 38.8
9,0 34.0
11,6 39.2
9,2 34.4
11,8 39.6
9,4 34.8
12,0 40.0
The actual surface temperature can deviate signifi-
cantly from the set floor temperature depending
on the structure.
9 Changing the batteries
C
see
[page 2]
CAUTION
Risk of explosion caused by improper replacement!
Improperly used batteries may explode and damage the
device or injure the user.
•
Replace batteries only with the same or an equivalent
type.
•
Do not use rechargeable batteries.
•
Never recharge batteries.
•
Do not throw batteries into fire or expose them to
excessive heat.
•
Do not short-circuit batteries.
WARNING
Danger to life due to ingestion
Small children can swallow batteries / setpoint adjusters.
•
Do not leave the device unattended when changing the
battery.
The device restarts after the battery has been changed.
Previously set values are restored.
10 Maintenance
Clean the appliance with a soft, clean, dry and lint-free cloth.
11 Factory reset
A factory reset resets the room control unit to the factory
settings. The pairing of the room control unit with the Base
Station is cancelled. For a simultaneous factory reset of several
paired room control units, a factory reset must be carried out
on the Base Station. If necessary, the pairing process must
then be carried out again for a room control unit that has been
unpaired. Information on this process can be found in the
installation instructions for the Alpha Smartware Base Station.
If necessary, the pairing process must be repeated for a de-
paired room control unit. Information on this process can be
found in the installation instructions for the Alpha Smart-
ware base station.
1. Press and hold
for > 3 seconds
Opens the settings
2. Press
to navigate to the menu rAL (Reset all)
3. Press
to confirm the selection
4. Press
in order to navigate to the menu item YES
Factory reset
DE
EN
FR
NL
IT
ES
DA
NO
FI
SV
PL
EL
TR
13
