Commissioning
7 Commissioning
Requirements for use
Pairing of room control unit LED – Alpha Smartware Base Sta-
tion Standard:
– Base Station with firmware version 2.10 or higher
Pairing room control unit LED – Alpha Smartware Base Station
Premium:
– Room control units with firmware version 3.00 or higher
Information on this process can be found in the instal-
lation instructions for the Alpha Smartware base station.
Operation of the Alpha Smart system in the Alpha Smart
Cloud:
– Alpha Smartware IoT Gateway
DE
The Alpha Smartware IoT Gateway enables the system to be
set up and controlled with the Alpha Smart app and is a ba-
EN
sic requirement for connecting Alpha Smartware compo-
nents to the Alpha Smart Cloud.
FR
A maximum of 50 Alpha Smartware devices may be
NL
used within a radius of 50 meters. A larger setup is
technically possible, but not validated currently.
IT
7.1
Pairing devices
ES
To be able to use the device to control a heating zone, it
DA
NO
must first be paired with the Alpha Smartware Base Station.
Information on this process can be found in the Quick Install
FI
Guide and installation instructions for the Alpha Smartware
Base Station.
SV
7.2
Registering devices (cloud operation)
PL
Requirements for use
EL
– Alpha Smartware IoT Gateway
TR
– Alpha Smart App
– User account is created in the Alpha Smart app
– Existing connection to a WiFi network within radio
range
Alpha Smart App
Alpha Smartware devices are connected in a system. To in-
tegrate new devices into this system, they must first be reg-
istered in the Alpha Smart Cloud.
1. Start the Alpha Smart app on the terminal
2. Select the Devices item in the menu
3. Add device with (+)
4. Scan the QR code or select a device manually
12
To use the device within the Alpha
Smart Cloud, it is necessary to use the
Alpha Smart app (download via QR
code).
5. Follow the instructions in the Alpha Smart app to add ad-
ditional devices
7.3
Remove devices from the app
1. Select device in the app
2. Open device options via
3. delete device
Removing a device from the app leads to "unclaim-
ing". The device can then be added again in the app
("claimed").
8 Function description
Different menu levels can be called up via the touch control
buttons
on the front of the
app offers additional operating functions.
Press and hold the button
menu level. Then navigate through the menu by using the
buttons
.
Pair
Pair room control unit with base station / train
to heating zone
Temperature
Floor sensor settings
Chap. 8.1 Floor sensor
low
Minimum temperature setting (18 °C ... 28 °C)
HIGH
Maximum temperature setting (30 °C ... 40 °C)
reset ALL
Perform a factory reset
State of Firmware
Display firmware version of paired devices:
– Value 1: Firmware version room control unit
– Value 2: Firmware version base station
Signal
Display the signal strength in [%] between the
room control unit and the base station
back
Back to the main menu (Home)
Update
Update process in progress
(in the app top right)
device.
The Alpha Smart
for > 3 seconds to call up the
1,0 ... 6,0 (increment: 0,2)
oFF: deactivated (default)
7,0 ... 12,0 (increment: 0,2)
oFF: deaktiviert (default)
