10.4 Update
The update can take up to ten minutes. The web panel will then restart
automatically.
The file format ".swu" is supported. If the update file is stored on a USB stick,
browse to "/run/media/name of connected USB stick-sda1" or "/run/media/
name of connected USB stick-sdb1" after inserting the USB stick.
After tapping Update, the menu for the system update opens.
► Tap Select.
► Select the file for the update.
► Tap Update.
► If you want to preserve preferences or passwords after the update, select
Backup Settings or Backup root user.
Wait until the web panel is restartet.
10.5 Operate
After tapping Operate, the following functions are available:
– Export settings
– Import settings
– Shutdown system
– Exit application
– Export screenshots
– Reboot system
– Factory reset
Export settings
The settings can be stored on a USB stick or transferred via FTP.
USB sticks are shown in the following directories of the web panel:
– /run/media/name of connected USB flash drive-sda1
– /run/media/name of connected USB flash drive-sdb1
Shutdown system
The web panel will be shut down in standby mode. The status LED will be
illuminated orange. To restart the web panel, the power supply must be
stopped and restarted.
Export screenshots
Screenshots can be stored on a USB stick or transferred via FTP.
USB sticks are shown in the following directories of the web panel:
– /run/media/name of connected USB flash drive-sda1
– /run/media/name of connected USB flash drive-sdb1
