9.6
Configuring the VNC Viewer
Figure 9.1
VNC Viewer
► In the drop-down list, select VNC Viewer.
► Enter the IP address and port for the VNC server.
The port must be entered immediately behind the IP address, separated by a
colon.
► Enter the password for the VNC server.
The address and password must have been specified when setting up the
VNC Server.
► If entries via the webpanel shall be impossible, enable View only (inputs
ignored).
The connected computer is controlled via the touch input of the web panel.
Keyboard input is only possible through a USB keyboard connected to the
web panel.
► Enable Full screen mode or Fit window mode.
► Set the Image Quality (transmission quality).
► Tap Apply to save the settings.
► Restart the web panel to start the VNC Viewer.
Only the desktop of the web panel is displayed initially. After about a minute,
the VNC Viewer starts the image transfer.
56
Operating instructions – u-view web panels
