Operating instructions – u-view web panels
3.2
Device description
1
3
4
5
6
7
Figure 3.1
Device description UV66-ADV-...
1
Touch display
2
LED display operating status
3
Earthing screw
4
DC supply voltage
5
USB-A
6
LAN A
7
LAN B
8
RS-232/422/485 (not functional)
9
RS-485/CAN (not functional)
10 VESA mounting hole
11
Mounting hole
10
2
8
9
10
11
