• Temperature
- Operating temperature of thermostat
- Operating temperature of single-lever
shower mixer
- Rating
- Weight
• Thermal disinfection possible
• Water connection:
• Hand shower connection:
Soap cartridge
• Filling quantity
Temperature
Conditions
• Notification mode:
• No cleaning mode, no cartridge replacement
• Soap consumption
Time setting (in s)
4
7
10
12
15
60
Rechargeable battery
• Type:
• Voltage:
• Capacity:
• Charging time 0 to 100%:
• Operating temperature:
• Storage temperature
- < 1 month:
- < 1 year:
• Weight:
Charger
• Power
- Input:
- Output:
• Protection class:
• Operating temperature:
• Storage temperature:
• Weight:
• Mains plug:
- EU:
- CN:
- ME:
• LED display
- No light:
- Orange light:
- Green light:
- Blinking orange light:
Special accessories
• Glue syringes
Installation
Assembly of the Foam Shower device
When installing e.g. on plasterboard walls (not solid walls) it
must be assured that an appropriate reinforcement is in place
to ensure sufficient strength.
max. 70 °C
max. 45 °C
Total consumption (in ml)
< 3.45
< 4.95
< 6.45
< 7.45
< 8.95
30
Lithium ion
2000 mAh
10 – 45 °C
-20 – +45 °C
-20 – +25 °C
AC 100 – 240 V, 50/60 Hz, 0.5 A
DC 16.4 V
Rechargeable battery not inserted
Fully charged
40915000
Installation with glue syringes
When installing with glue syringes, ensure that all four glue
points are used. The 24-hour curing time of the glue must be
observed.
IPX5 Water connection
2.4 kg
The Foam Shower hand shower is attached to the front G1/2
connection nipple via a shower hose.
Back For the water supply, the existing shower faucet is attached to
the rear G1/2 connection nipple via a shower hose.
Front
These two connections must not be mixed up!
250 ml
Operation
5 – 45 °C
"Power" button
<2s
Operation
Push
Push + hold
"Mode" button
Operation
Push
Push 2x – 5x
14.8 V
Push + hold
~3 h
Default mode (shower mode)
• Default setting when the rechargeable battery is inserted
• No LED indicator if the remaining battery life is >15%
• If the remaining battery life <15%, the LED lights orange.
258 g
Status display mode for battery life
• This mode allows the user to check the remaining battery
life.
• To reduce power consumption, this mode is only activated
for 3 seconds if the "Mode" button is pushed and held in the
II
default mode. After this, the device is automatically returned
0 – 40 °C to default mode.
Foam mode
0 – 60 °C
• This mode releases foam from the hand shower.
168 g
• In this mode, the LEDs light in a pattern that symbolises the
remaining application time.
Type C
• To enable flexible application, the "Power" button can be
Type A
pushed during the foam mode to switch back to the shower
Type G
mode regardless of the remaining application time.
Mode for setting time
• This mode is used to change the application time of the
Charging
foam mode.
• In the default setting, the application time is 10 seconds.
Error
• If this mode is activated, the white LEDs light in a pattern
that symbolises the application time of the foam mode that
the previous user set. Five time settings can be chosen by
pushing the "Mode" button again.
• Only one application time can be set. The previous setting is
deleted when a new application time is chosen.
• The time set by the user is saved in the memory for at least
48 hours thanks to Flash memory (non-volatile memory),
even if removed from the power supply.
23
Mode
Foam mode
Cleaning mode
Mode
Mode for setting time
Selection of different time
intervals
Battery life status display
