HUUM CORE6 Montage- Und Bedienungsanleitung Seite 5

min 1200
CORE Black
H
A
min 1200
CORE BK/ST
H
A
Figure 1 Positioning of the heater
Screw down the legs (4 pcs) included in the package. Adjust the legs of the heater so
that all four are equally supported and the heater is level.
NB! Unfinished CORE Body model needs finishing. See Appendix 1 (pages 15-16)
for recommendations for finishing.
NB! A finished heater can become very heavy and difficult to rotate to make the
electrical connection. Before installing the finish and riveting the slats, connect
the cables under the heater and check the operation of the heater.
A A
min 25
A A
min 25
A
A
5
