ENGLISH
Automatic speed setting
The robot automatically adjusts its speed during the cleaning process and reverses direction
when it bumps into walls.
Malfunctions
If there is a problem with the Hall sensor, the red indicator light will flash once per second and
beep.
If the robot does not detect that it is in the water, the red indicator light will flash twice per
second and beep.
Removing the robot from the pool
Use the hook to pull the robot out of the water.
Repeating the cleaning process
If desired, repeat steps 2-7 until the pool is completely clean.
Low battery
If the battery runs out during the cleaning process, the robot will move to the nearest pool
edge. The red indicator light will remain steadily on.
To pick up the robot, use the hook and then charge it as described above.
Motion direction
The robot can go forward or backward (if it bumps into a wall).
Fitting and removing the wheels
Figure 8 shows how to fit the side wheel (pay attention to the direction indicated by the arrow).
Figure 9 shows how to fit the front and rear wheels.
To remove them, simply reverse the process.
4. CLEANING AND MAINTENANCE
1. Disassembling the robot Fig. 10
Loosen the four latches on each side of the robot. Slowly lift the top cover. Start by unlocking
the latches in positions 3 and 4 first, and then continue with positions 1 and 2.
2. Cleaning the robot
Clean the filter and body as shown in figure 11.
Note:
- The wheels can gather debris while in the pool, especially the left and right wheels. If they
are not cleaned in time, they may clog. Fig. 12
