ENGLISH
Note: to empty the accumulated water through the drain hose, place a container underneath to
prevent water from spilling onto the floor.
End-of-season maintenance:
1.
Remove the inner drain hose and drain the water into a container or pull out the outer
drain hose directly to drain the water from the tank through the window.
2.
To allow the inside of the tube to dry out, let the air conditioner run in Fan mode at the
lowest speed for a few hours or activate the self-cleaning function. In this way, the inside
of the unit will dry out completely, which will help prevent the formation of mould and
mildew.
3.
Switch off the appliance, unplug it from the socket, wind up the power cable and put the
drain hose back in place.
4.
Remove the air conditioner from the window and remove the installation bracket.
5.
Put the appliance in a plastic bag and store it in a cool, dry place to prevent dust
accumulation. Store it out of the reach of children.
6.
Remove the remote control batteries.
Note: make sure that the air conditioner is installed in a dry place and that all components are
well protected.
5. TROUBLESHOOTING
Do not attempt to repair or disassemble the air conditioner yourself. Any unauthorised repair
will void the product warranty, as well as jeopardise the safety of the user.
Problem
Possible causes
The appliance is not plugged in or
there is no power supply.
The full tank warning "FL"
appears on the display.
The room temperature is too low
The appliance does
or too high.
not work
The room temperature is lower
than the temperature selected in
Cooling mode.
The room temperature is
too low to be able to select
Dehumidification mode.
70
WINDOWCLIMA 9000 INVERTER
Solutions
Once plugged into the power socket,
press the power button.
Empty the tank.
It is recommended to place the
appliance in a room with a room
temperature between 7 and 35 °C.
Change the selected temperature.
Place the appliance in a room with a
room temperature above 17 °C.
The appliance is exposed to
direct sunlight.
Doors and windows are open,
Poor cooling
or the installation bracket is not
well sealed, and there are too
many people in the room or other
sources of heat.
The air filter is dirty.
The air inlet or outlet is blocked.
There is a strange
The appliance is not well
noise
installed.
The compressor
The overheating protection
does not work
system has been activated.
The distance between the remote
The remote control
control and the appliance is too
does not work
great.
The remote control is not
correctly oriented to the air
conditioner receiver.
The batteries have run out.
E1
Indoor unit pipe temperature
sensor failure.
E2
Room temperature sensor failure
E4
Leakage or failure of the cooling
system due to low temperature.
E5
Water pump failure.
EF or EC
Motor fan failure.
ENGLISH
Protect the appliance from sunlight.
Close the door or window or seal the
bracket tightly.
Clean or replace the filter.
Perform maintenance on grilles.
Check that the air conditioner bracket
and the air conditioner itself are
correctly installed.
Wait for 3 minutes until the
temperature is lowered, and then
restart the appliance.
Move the remote control closer to
the air conditioner and make sure it is
pointing directly at the receiver.
Replace batteries.
Contact the official Cecotec Technical
Support Service.
Contact the official Cecotec Technical
Support Service.
Place the appliance in a room with a
higher room temperature.
Contact the official Cecotec Technical
Support Service.
Contact the official Cecotec Technical
Support Service.
Contact the official Cecotec Technical
Support Service.
71
WINDOWCLIMA 9000 INVERTER
