Figure 4
Figure 5
The stimulation of the current frequency can be displayed during
the stimulation by means of the key
period in minutes will be shown in the centre of the display.
Stopping the Stimulation
The stimulation will stop automatically when the whole running
period of the program has expired. This will be confirmed by a signal
tone. However, it is possible to end the stimulation prematurely
with the key
or
Editing the Stimulation Parameters
After a program has been selected and the
operated twice, it will be possible to edit the stimulation parameters
of the relevant program. This will be confirmed by a signal tone.
The starting values will be based on the parameters of each
program. Press the key
over the values according to the last parameter.
The values can be edited with the help of the modification keys
. If these keys are held down, the selected parameter will be
further reduced or increased automatically.
When the frequency is being set, it will be raised in steps of 1000
with the two left modification keys. The frequency will be changed
in steps of 1 with the two right modification fees.
The following parameters can be edited:
•
Frequencies (
): 1 Hz to 999999 Hz (Figure 4)
•
Period of stimulation: 1 to 90 min. (Figure 5)
If the period of stimulation is changed in the 'P' type of operation,
only the length of the first stimulation sequence will be changed.
If the period of stimulation is changed in the 'F' type of operation,
the whole period of stimulation will be changed. It is only possible
to change the time in 6-minute steps. The whole period of the
individual sequences must be divided by 6, to ascertain the length
of the individual sequences.
After processing the last parameter, press the key
the parameters. This will be confirmed by a signal tone.
. The remaining stimulation
.
to jump to the next parameter or to take
English
key has been
again, to store
21
