Type AFTF-T3-MB | Telegrams
TELEGRAMS
Function 04 Read Input Register
Register Parameter
3x0001 Temperature
3x0002 Temperature
3x0003 Relative humidity
Relative humidity
3x0004
3x0005 Dew point
3x0006 Absolute humidity
3x0007 Mixing ratio
3x0008 Enthalpy
Function 05 Write Single Coil
Register Parameter
0x0001 reserved
0x0002 System of units
Temperature
Relative humidity
Dew point
Absolute humidity
Mixing ratio
Enthalpy
134r0068/002;1: Frozen :29-Jan-2024
Data Type
Sampling 4 s Signed 16 Bit
Filtering 32 s Signed 16 Bit
Sampling 4 s Signed 16 Bit
Filtering 32 s
Signed 16 Bit
Computed value Signed 16 Bit
Computed value Signed 16 Bit
Computed value Signed 16 Bit
Computed value Signed 16 Bit
Data Type
SI → Imperial
[°C] → [°F]
[% RH] [% RH]
[°C] → [°F]
[g / m³] [gr / ft³]
→
[g / kg] → [gr / lb]
[kJ / kg] [Btu / lb]
→
15
Value
– 350... +800
– 310...+1760
– 350... +800
– 310...+1760
0...1000
0...1000
0... 500
320...1220
0...800
0...349
0... 800
0...5600
0...850
0...360
Value
Bit 1 0 / 1
Range
– 35.0... +80.0 °C
– 31.0...+176.0 °F
– 35.0... +80.0 °C
– 31.0...+176.0 °F
0.0...100.0 % RH
0.0...100.0 % RH
0.0... +50.0 °C
32.0...+122.0 °F
0.0...80.0 g / m³
0.0...34.9 gr / ft³
0.0... 80.0 g / kg
0.0...560.0 gr / lb
0.0...85.0 kJ / kg
0.0...36.0 Btu / lb
Range
SI (Default) -
Imperial
