m ATTENTION
If the PIN code is entered incorrectly 10 times, "LOCK"
appears on the display. The device is now locked for
10 minutes before you can enter the PIN code again.
• Press the "START" button and then the "OK" button
to start mowing.
• If you press the "HOME" button and then the "OK"
button, the robotic lawnmower (1) returns to the
charging station (10) with the mowing function
switched off.
The robotic lawnmower (1) operates continuously un-
til the battery charge is too low. The robotic lawnmow-
er automatically returns to the charging station (10).
The cutter disc is deactivated in this state.
m NOTE
After the battery is fully charged, the robotic lawn-
mower starts again. Alternatively, the robotic lawn-
mower remains in the charging station (10) in accord-
ance with the set mowing schedule.
(By default, the robot mows from Monday to Friday
from 09:00 - 15:00 hrs)
9.2. Settings
m NOTE
To make adjustments to the product, the robotic lawn-
mower (1) must be switched on. Switch on the robotic
lawnmower (1) by pressing and holding the
("POWER ON/OFF" button) until "PIN" appears on
the display.
9.2.1 Changing the PIN code (Fig. 21)
• Press and hold the "START" and "HOME" buttons
simultaneously for at least 3 seconds.
• The symbol
and "PInI" flash.
• Now enter the old PIN code as follows (factory set-
ting "0000").
• The first digit illuminates ("0---").
• Use the "START" and "HOME" buttons to select the
desired digit.
• Confirm the digit with the "OK" button.
• The next digit illuminates (e.g. "10--).
• Proceed as described in paragraph 2-4 above.
• After you have entered the "old" PIN code and con-
firmed the fourth digit with the "OK" button, "PIn2"
appears, now you can enter the new PIN code.
• The first digit flashes ("0---").
• Use the "START" and "HOME" buttons to select the
desired digit.
• Confirm the digit with the "OK" button.
• The next digit flashes (e.g. "10--).
• Proceed as described in paragraph 2-4 above.
• After confirming the fourth digit with the "OK" but-
ton, the new PIN code is stored. The word "IdLE"
appears on the display.
30 | GB
9.2.2 Setting/changing the date/time (Fig. 22)
m NOTE
Date and time are necessary settings so that the ro-
botic lawnmower (1) can mow in accordance with the
set mowing schedule.
• The date/time setting is done in the order year - date
- time.
• Press and hold the "START" button for at least 5
seconds.
• The
on the display.
• Use the "START", "HOME" and "OK" buttons to set
the year, similarly to the PIN setting.
• Then the next number illuminates (month.day e.g.
08.25 for 25 August).
• Use the "START", "HOME" and "OK" buttons to set
the correct month and day.
• The time is displayed last (e.g. 13:25).
• Set the current time as described above.
• After confirming the fourth digit with the "OK" but-
ton, the date and time are stored. The word "IdLE"
appears on the display.
9.2.3 Changing the start time (Fig. 23)
The factory-set start time of 09:00 can be changed at
any time.
-button
• Press and hold the "START" and "OK" buttons si-
multaneously for at least 3 seconds.
• The display shows the set start time, e.g. 13:25, with
the first digit flashing.
• Use the "START" and "HOME" buttons to select the
desired digit and confirm with the "OK" button.
• Proceed as described in paragraph 2-4 above.
• After confirming the fourth digit with the "OK" but-
ton, the new start time is stored. The word "IdLE"
appears on the display.
9.2.4 Changing the mowing time/day (Fig. 24)
The factory-set mowing time per day of 6 hours can
be changed at any time.
• Press and hold the "OK" button for at least 3 sec-
onds.
• The display shows the set mowing time, e.g. 06 H,
with the first digit flashing.
• Use the "START" and "HOME" buttons to select the
desired digit and confirm with the "OK" button.
• After confirming the second digit with the "OK" but-
ton, the new mowing time or the new day is stored.
The word "IdLE" appears on the display.
www.scheppach.com
-symbol and a number (e.g. 2020) flashes
