Operating the hand-held transmitter
• Initial programming of the wireless remote control is necessary prior to its first
use. Please follow the description in the „Programming" chapter.
Key assignment:
Remote control:
Operation of the remote control
Switching
on/off:
Start-up:
Dimming:
Auto-Stop:
Memory-
function:
Synchronisation: If multiple radiant heaters are controlled using the same hand-
6131173,
04/2020
Keys 1-4: Wireless channel keys
Key 5: Special key
Transmission frequency: 433.92 MHz
Battery: CR 2032, 3 volt
Range: approx. 20 m with an unimpeded
path through air
Brief pressing of the programmed radio channel button on the
hand-held transmitter switches the radiant heater on or off.
Long pressing of the button on the hand-held transmitter incre-
ases the heat output of the radiant heater from the switched off
state to the desired heat output.
Pressing and holding of the button on the hand-held trans-
mitter adjusts the heat output continuously up or down to the
maximum or minimum position (30%).
The dimmer stops automatically upon reaching the maximum
or minimum position, even if the button remains pressed.
Upon switching back on, a short press of the button recalls the
last heat output setting.
held transmitter button, faults in the radio transmission path
can result in different heat output settings. For synchronisati-
on, use the function „Start-up" to initially set all radiant heaters
in the switched-on state. Then switch off all receivers by a brief
button press. Now the „Start-up" function can be used to simul-
taneously set all the actuated receivers again.
66
1 2
5
3 4
